Infineon英飛凌IPM智能功率模塊

發布時間：2024-01-29 11:49:17     瀏覽：852

基于不同半導體技術、采用不同封裝、適用不同電壓和電流等級的IPM智能模塊，分為緊湊型系列、標準系列和高性能系列。我們的IPM智能模塊系列包括 CIPOS? Nano、CIPOS ? Micro、CIPOS ? Mini和CIPOS? Maxi等。這些高能效智能功率模塊IGBT集成了最先進的功率半導體和IC技術。

這些智能功率模塊能效高，集成了新功率半導體和控制芯片技術，并運用了英飛凌先進的IGBT、MOSFET、新一代柵極驅動 IC和新型熱機械技術。通過提高功率密度、增強系統耐用性和可靠性，該系列模塊有效提升了系統性能和能效。

產品選型：

ProductPackageProduct GroupVoltage Class [V]Switch TypePmot 10kHz [W]Rated Current [A]
IM818-LCCDIP 36x23DCIPOS? Maxi1200IGBT315
IM818-MCCDIP 36x23DCIPOS? Maxi1200IGBT2.210
IM818-SCCDIP 36x23DCIPOS? Maxi1200IGBT1.45
IM828-XCCDIP 36x23DCIPOS? Maxi1200CoolSiC?4.820
IM241-L6S1BSOP 29x12 CIPOS? Micro600IGBT4506
IM241-L6T2BDIP 29x12 CIPOS? Micro600IGBT4506
IM241-M6S1BSOP 29x12 CIPOS? Micro600IGBT3254
IM241-M6S1JSOP 29x12 CIPOS? Micro600IGBT3254
IM241-M6T2BDIP 29x12 CIPOS? Micro600IGBT3254
IM241-M6T2JDIP 29x12 CIPOS? Micro600IGBT3254
IM241-S6S1BSOP 29x12 CIPOS? Micro600IGBT2002
IM241-S6S1JSOP 29x12 CIPOS? Micro600IGBT2002
IM241-S6T2BDIP 29x12 CIPOS? Micro600IGBT2002
IM241-S6T2JDIP 29x12 CIPOS? Micro600IGBT2002
IFCM20T65GDDIP 36x21DCIPOS? Mini650IGBT360020
IFCM20U65GDDIP 36x21DCIPOS? Mini650IGBT440020
IFCM30T65GDDIP 36x21DCIPOS? Mini650IGBT540030
IFCM30U65GDDIP 36x21DCIPOS? Mini650IGBT640030
IFCM10P60GDDIP 36x21DCIPOS? Mini600IGBT120010
IFCM10S60GDDIP 36x21DCIPOS? Mini600IGBT120010
IFCM15P60GDDIP 36x21DCIPOS? Mini600IGBT180015
IFCM15S60GDDIP 36x21DCIPOS? Mini600IGBT180015
IGCM04F60GADIP 36x21CIPOS? Mini600IGBT6004
IGCM04G60GADIP 36x21CIPOS? Mini600IGBT6004
IGCM06F60GADIP 36x21CIPOS? Mini600IGBT8006
IGCM06G60GADIP 36x21CIPOS? Mini600IGBT8006
IGCM10F60GADIP 36x21CIPOS? Mini600IGBT100010
IGCM15F60GADIP 36x21CIPOS? Mini600IGBT120015
IGCM20F60GADIP 36x21CIPOS? Mini600IGBT160020
IKCM10H60GADIP 36x21CIPOS? Mini600IGBT100010
IKCM10L60GADIP 36x21CIPOS? Mini600IGBT120010
IKCM15F60GADIP 36x21CIPOS? Mini600IGBT160015
IKCM15H60GADIP 36x21CIPOS? Mini600IGBT120015
IKCM15L60GADIP 36x21CIPOS? Mini600IGBT160015
IKCM15L60GDDIP 36x21DCIPOS? Mini600IGBT220015
IKCM20L60GADIP 36x21CIPOS? Mini600IGBT180020
IKCM20L60GDDIP 36x21DCIPOS? Mini600IGBT240020
IKCM20R60GDDIP 36x21DCIPOS? Mini600IGBT240020
IKCM30F60GADIP 36x21CIPOS? Mini600IGBT200030
IKCM30F60GDDIP 36x21DCIPOS? Mini600IGBT260030
IM523-L6ADIP 36x21CIPOS? Mini600IGBT120015
IM523-M6ADIP 36x21CIPOS? Mini600IGBT80010
IM523-S6ADIP 36x21CIPOS? Mini600IGBT6006
IM523-X6ADIP 36x21CIPOS? Mini600IGBT140017
IM535-U6DDIP 36x21DCIPOS? Mini600IGBT300030
IM564-X6DDIP 36x21DCIPOS? Mini600IGBT240020
IGCM04G60HADIP 36x21CIPOS? Mini600IGBT6004
IKCM15R60GDDIP 36x21DCIPOS? Mini600IGBT220015
IM111-X6Q1BQFN 12x10CIPOS? Nano600CoolMOS?2002
IRSM807-045MHQFN 8x9 CIPOS? Nano500MOSFET1304
IRSM807-105MHQFN 8x9 CIPOS? Nano500MOSFET20010
IRSM808-105MHQFN 8x9 CIPOS? Nano500MOSFET20010
IRSM836-025MAQFN 12x12CIPOS? Nano500MOSFET552
IRSM836-035MAQFN 12x12CIPOS? Nano500MOSFET703
IRSM836-035MBQFN 12x12CIPOS? Nano500MOSFET703
IRSM836-045MAQFN 12x12CIPOS? Nano500MOSFET804
IM111-X3Q1BQFN 12x10CIPOS? Nano250OptiMOS?2004
IRSM808-204MHQFN 8x9 CIPOS? Nano250MOSFET20020
IRSM836-024MAQFN 12x12CIPOS? Nano250MOSFET402
IRSM836-044MAQFN 12x12CIPOS? Nano250MOSFET604
IRSM836-084MAQFN 12x12CIPOS? Nano250MOSFET857
IRSM005-301MHQFN 7x8CIPOS? Nano100MOSFET165
IRSM005-800MHQFN 7x8CIPOS? Nano40MOSFET16580
IRSM836-015MAQFN 12x12CIPOS? Nano500MOSFET501
IM323-L6GDIP 33x19CIPOS? Tiny600IGBT120015
IM323-L6G2DIP 33x19CIPOS? Tiny600IGBT120015

深圳市立維創展科技有限公司，優勢分銷Infineon英飛凌部分產品線，快速交付，歡迎聯系。
